The SY5002 is a low quiescent current and low dropout voltage regulator with output voltages between 0.85 V and 5.0 V capable of delivering up to 300 mA.
SY5002 has an automatic discharge function to quickly discharge VOUT when EN is disabled.
SY5002 feature Over-current protection, Thermal Shutdown and Auto-discharge function.
The SY5002 is offered in the DFN1X1-4/SOT23-5 package.
Low dropout voltage：VDO = 196 mV (typ.) at 3.3 V-output, IOUT = 300 mA
Quiescent current: 0.55uA
Stand-by current: 0.03uA
Input voltage range: 1.8~5.5V
Fixed output voltage: 1.8V,3.3V (Other output voltage versions need to be customized)
High output voltage accuracy: ±1.0 % (1.8 V ≤ VOUT)
Output current: 300mA (MAX)
Auto-discharge
Over-current protection
Thermal Shutdown
Available in two different packages: DFN1X1-4 and the SOT23-5 package
Wearable devices
IoT devices
Portable applications
