The TS5110 is a high-accuracy digital temperature sensor. It is fully compliant with JEDEC JESD302-1 specification.
The TS5110 device is intended to operate up to 12.5 MHz on a 1.0V I3C Basic bus or up to 1 MHz on a 1.0 V to 1.2 V I2C bus. When the device is in I3C mode,it supports the in-band interrupt (IBI) function.
The device provides +/-0.25°C typical sensing accuracy, over the entire operating temperature range of -40°C to +125°C. The detection frequency is greater than 8 samples/s, realize real-time monitoring of ambient temperature. By setting reasonable upper and lower temperature thresholds, and generate temperature interruption events to avoid operating exceptions caused by over temperature.
The TS5110 is available in a 6-pin CSP (0.85mmx1.35mm) package.
Compliant with JEDEC JESD302-1
Operating temperature range：-40℃~+125℃
Exceeds JEDEC temperature accuracy specifications：(typ./max.)：±0.25°C / ±0.5°C from +75°C to +95°C；±0.25°C / ±0.75°C from -40°C to +125°C
Sample frequency：>8samples/s
Low power consumption: Working average current: 2.6uA；Standby current:1.0uA
Operating voltage range: 1.70V~1.98V（VDDSPD）;0.95V~1.05V（VDDIO）
Support 1MHz I2C and 12.5MHz I3C Bus
Configurable temperature threshold
Support PEC and PAR Function
Support the In Band Interrupt
6-pin CSP (0.85mmx1.35mm) package
DDR5 DIMM
Server
Notebook computer
Workstation
SSD
