The SY5401 develops a peak current mode control, asynchronous buck DC/DC converter capable of delivering 3A output current. The SY5401 operates over a wide input voltage
range from 5V to 100V and integrates main switch with very low RDS(ON) to minimize the conduction loss. The regulator has an ultra-low current of 15uA in off mode for extended battery life. The internal
loop compensation means that the user does not have to undertake the tedious work of designing loop compensation components and can also minimize the number of external
components of the IC. The switching frequency is adjustable from 200kHz to 500kHz using an external resistor. In addition,
the device has a variety of built-in protection features: cycle-by-cycle peak current limit protection(current limitis typical 5A), thermal shutdown protection, and over-voltage and under-voltage protection.
Low RDS(ON) for Internal N-channel Power FET(TOP):130m?
5-100V Input Voltage Range
1V ~30V Output Voltage Range
3A Output Current Capability
Adjustable Switching Frequency Range：200kHz to 500kHz
0.8V± 1% Reference Voltage Accuracy
5A Cycle-by-cycle Peak Current Limit
Internal Soft-start Limits the Inrush Current
Internal compensation for easy use
15uA Shutdown Current
Compact Package: ESOP8
Non-isolated Telecommunication Buck Regulator
Secondary High Voltage Post Regulator
High-Power LED Drivers
GPS Tracker
Automotive Systems
Electric Bicycle
